SC(B)10-125~4000/10
Brand Name: Zhejiang Guangtian
Model Number: SC10-125~4000/10
Phase: 3 phase
Rated Voltage: 10kV
Rated Capacity: 125kVA~4000kVA
Frequency:50HZ
Vector Group: Dyn11
Certification: ISO/CE
Standard: IEC60076, T/CEEIA 258-2016
Cooling Method: AN/AF
OEM: Accepted
MOQ: 1 unit
SC10-30~100/10 epoxy resin cast dry-type transformer
Brand Name: Zhejiang Guangtian
Model Number: SC10-30~100/10
Rated Voltage: 10kV
Rated Capacity: 30kVA~100kVA
Vector Group: Dyn11
Cooling Method: AN/AF
MOQ: 1 unit
E-mail：sales@guangtian.cn
Tel/Wechat/WhatsApp：86-15958694455
- Commodity name： SC(B)10-125~4000/10
Category:
Keywords：
Dry-Type Transformers
Product Introduction
The low-tension coil is wound and cured with insulating cloth which is pre-impregnated by copper foil and epoxy resin. The iron core is made of high permeability cold-rolled grain-oriented silicon steel sheets with smaller magnetostriction, the processing of which is supported by the longitudinal and transverse shear, as well as an iron core stacking and flipping table, so as to ensure excellent performance. The application of multi-step stacking process homogenizes magnetic flux and reduces noise and loss. The product functions excellently due to its strong short-circuit resistance, safety and reliability, environmental protection and energy conservation, and direct operation in the load center.
- 产品描述
Get a quote
If you are interested in our products, please leave your contact information and we will contact you as soon as possible. Thank you.
