  • Dry-Type Transformers-2.jpg

Dry-Type Transformers

The Chinese- style box transformer developed by the company has obvious advantages of low cost. The large-capacity Chinese box transformer product is small in size.

The low-tension coil is wound and cured with insulating cloth which is pre-impregnated by copper foil and epoxy resin. The iron core is made of high permeability cold-rolled grain-oriented silicon steel sheets with smaller magnetostriction, the processing of which is supported by the longitudinal and transverse shear, as well as an iron core stacking and flipping table, so as to ensure excellent performance. The application of multi-step stacking process homogenizes magnetic flux and reduces noise and loss. The product functions excellently due to its strong short-circuit resistance, safety and reliability, environmental protection and energy conservation, and direct operation in the load center.

  • Commodity name: Dry-Type Transformers

Keywords:

Dry-Type Transformers

Product Introduction

  • 产品描述

The low-tension coil is wound and cured with insulating cloth which is pre-impregnated by copper foil and epoxy resin. The iron core is made of high permeability cold-rolled grain-oriented silicon steel sheets with smaller magnetostriction, the processing of which is supported by the longitudinal and transverse shear, as well as an iron core stacking and flipping table, so as to ensure excellent performance. The application of multi-step stacking process homogenizes magnetic flux and reduces noise and loss. The product functions excellently due to its strong short-circuit resistance, safety and reliability, environmental protection and energy conservation, and direct operation in the load center.

Get a quote

If you are interested in our products, please leave your contact information and we will contact you as soon as possible. Thank you.

Submit
